Solar Products Line Up
Products
Solar Wafer
Silicon single crystal wafer for solar cell use
-
Wafer,as a basis of solar cell,is produced by thinly slicing silicon ingot.
We supply wafer with excellent quality.
Moreover,we supply not only bare wafer but also processed wafer.
Tex processed wafer (Wafer conducted with Tex process.Tex size can be discussed)
Diffusion wafer(diffused wafer.PSG film removed)
| Product | Silicon single crystal wafer for solar cell use |
| Conductivity | P/N |
| Dimension | 125mm / 156mm |
| Thickness | 180um~ |
| Resistivity | 0.5~3Ohm.cm / 3-6Ohm.cm |
Solar Cell
125mm Single crystalline solar cell
| Item | 125mm Single crystalline solar cell |
| Dimension | 125mm × 125mm ± 0.5mm |
| Diameter | φ150mm ± 0.5mm |
| Thickness | 200um ± 30um |
| Front | 1.5 mm busbar (silver) |
| Silicon Nitride antireflection coating | |
| Back | 2.5mm continuous soldering pads(silver/aluminium) |
| Back surface field (aluminium) |
156mm Multi crystalline solar cell (2bus bar)
| Item | 156mm Multi crystalline solar cell (2bus bar) |
| Dimension | 156mm × 156mm ± 0.5mm |
| Thickness | 200um ± 30um |
| Front | 2.0 ± 0.1mm busbar (silver) |
| Silicon Nitride antireflection coating | |
| Back | 3.0mm continuous soldering pads(silver) |
| Back surface field (aluminium) |
156mm Single crystalline solar cell (2bus bar)
| Item | 156mm Single crystalline solar cell (2bus bar) |
| Dimension | 156mm × 156mm ± 0.5mm |
| Diameter | φ200mm ± 0.5mm |
| Thickness | 200um ± 30um |
| Front | 2.0 ± 0.1mm busbar (silver) |
| Silicon Nitride antireflection coating | |
| Back | 3.0mm continuous soldering pads(silver) |
| Back surface field (aluminium) |
Cell semi-finish item (AR coat finish)
Solar Module
Solar Module
- formed by solar cells
- Solar module is formed
by solar cells
which are built into frame
